Drive mode: 4×4, 4×2
Rated Power kW（hp）:40/50/100/110/120/130/150/180/200
Maximum traction force (KN): ≥38
Adopt German ZF power shift transmission, 40F+40R gear

Scope Of Operation: It can be used for various operations such as basic construction of farmland, grain accumulation in yards, ice and snow removal in wintering fishing ponds, and removal of ice on roads.

Tractor Manufacturers - Best Prices

Get A Free Quote Send Inquiry Now!

Product Introduction
Product Features
Related Cases
Related Products

Product Introduction

Agricultural Tractor-Factory Direct Sales

Farm Tractors –Professional Manufacturer

1.The main features match the National III standard Weichai Deutz diesel engine, with large torque reserve and good power economy;
2.It adopts German ZF power shift gearbox, 40F+40R gears, rich gears, reasonable matching and high efficiency;
3.The Italian CARRARO front drive axle is adopted, with advanced mechanism and flexible operation;
4.The Bosch Rexroth electro-hydraulic system imported from Germany can realize various adjustment methods such as force adjustment, position adjustment, and comprehensive adjustment of force and position;
5.The power output is matched with four standard speed outputs (540, 540E, 1000/1000E) to meet the requirements of different operations and configuration of farm tools;
6.The new streamlined appearance is generous, modern and fashionable.

Product Features

Tractor Model		LT1004	LT1104	LT1204	LT1304	LT400	LT500	LT1000	LT1100
Drive Type		4×4	4×4	4×4	4×4	4×2	4×2	4×2	4×2
Overall Dimension L×W×H(mm)		4320×2038×2810	4650×2038×2970	5040×2255×2870	5040×2370×3000	3910×1620×2130	3910×1620×2130	4280×2038×2810	4334×2038×2925
Wheel base(mm)		2195	2449	2688.5	2688.5	1940	1940	2195	2449
Front wheel tread(mm)		1610	1610	1672-2003	1822-2153	1200-1500（common1300）	1200-1500（common1300）	1385-1685	1500
Rear wheel tread(mm)		1620-2020	1620-2020	1662-2262	1662-2262	1200-1500（common1300）	1200-1500（common1300）	1620-2020	1615
Min. ground clearance(mm)		379	379	470	470	330	360	470	470
Engine	Type	LR4B3ZU22/0735E	LR6M5ZU22/0810E	LR6M5ZU22/0882E	LR6A3ZU22/0956E	C490BT-8	A498BT-6A	LR4V5U22/0662E	LR6M5U22/0810E
	rated power kW（hp）	73.5（hp100）	81（hp110）	88.2（hp120）	95.6（hp130）	29.4（hp40）	36.8（hp50）	73.5（hp100）	81（hp110）
	r/min	2200	2200	2300	2200	2400	2400	2200	2200
Min.turning radius	Unilateral braking(m)	4.2±0.3	4.8±0.3	7	7	3.3	3.3	3.6±0.2	3.8±0.2
Min.turning radius	non-unilateral braking(m)	4.9±0.3	5.5±0.3			3.7	3.7	4.0±0.2	4±0.2
Min. operating weight (KG)		4090	4249	4850	4810	1840	1840	3670	3790
Number of gears	go ahead	16	16	12	12	12	12	16	16
Number of gears	step back	8	8	4	4	12	12	8	8
speed range	go ahead	0.44-33.34	0.44-33.34	2.19-29.63	2.19-29.63	2.46-34.02	2.46-34.02	0.44-33.44	0.44-33.44
speed range	step back	0.59-10.31	0.59-10.31	4.72-13.83	4.72-13.83	2.15-29.82	2.15-29.82	0.59-10.31	0.59-10.31
tire model	front wheel	11.2-24	11.2-24	14.9-26	14.9-26	6.00-16	6.00-16	6.5-20	6.5-20
tire model	rear wheel	16.9-34	16.9-34	18..4-38	18..4-38	12.4-28	13.6-28	16.9-34	16.9-34
Steering		Full hydraulic all-wheel steering
Max. lifting force( KN )		17.7	18.9	≥28	≥28	6.7	8.28	17.7	18.9
PTO	Type	rear, independent
	Speed (r/min)	760/1000 540/1000	760/1000 540/1000	540/1000	540/720	540/760 or 540/1000	540/760 or 540/1000	760/1000 540/1000 540/760 760/850	760/1000 540/1000 540/760 760/850
	Power(Kw)	59.4	65.4	71.25	81.7	≥25	≥31.3	59.4	65.4
Deep tillage control method		height control, float control
Max. traction force (KN)		24	25.7	27	32	8.9/9.4	10.7	19.3	21.6
Front / rear Ballast (KG)		270/320	270/320	500/300	600/400	104/220	104/220	270/320	270/320
