Concrete Mixing Plant Source Manufacturer-YALONG Machinery
Mobile Concrete Mixing Plant For Sale
Yalong machinery is a manufacturer for concrete mixing plant in china and manufacturing samll concrete palnt,mini concrete batch plant,portable concrete plant and so on.
-
-
Portable Concrete Batching Plant 50 m³/h
-
-
Mobile Concrete Batching Plant 75 m³/h
Parameter
Model |
HZS25 |
HZS35 |
HZS50 |
HZS60 |
HZS75 |
Rated productivity |
25m³/h |
35m³/h |
50m³/h |
60m³/h |
75m³/h |
Concrete mixer |
JS500 |
JS750 |
JS750 |
JS1000 |
JS1500 |
Mixer Power |
30kW |
30kW |
2*18.5kW |
2*18.5kW |
2*30kW |
Max. mixing size |
80mm |
80mm |
80mm |
80mm |
80mm |
Discharging height |
3800mm |
3800mm |
3800mm |
3800mm |
3800mm |
Aggregate feeding mode |
Belt Conveyor |
Max. Aggregate diameter |
80mm |
80mm |
80mm |
80mm |
80mm |
Weighing system |
Water, Cement, Additive |
Weighing precision |
±1% |
Control system type |
Computer auto-control module |
Features
1.Move easily. Trailer-style wheels and a special steel frame combination designed to make the equipment easy to move. With the exception of screw conveyors and bolted silos, all equipment can be towed and moved to the plant after the front is dropped.
2.The footprint is small, the mobile structure is more compact than the fixed structure, and the space occupied is relatively small.
High working efficiency As an auxiliary unit, we use a twin-horizontal axial drive mixer with excellent performance, which has the advantages of fast mixing speed and wide mixing range. Our equipment not only has high working efficiency, but also ensures stable concrete quality and performance.
3.The foundation cost is low, and the mobile concrete batching equipment can be installed at any time without special foundation. Customers only need to ensure that the site area and the ground are firm, which can help customers save costs.
4.The equipment has a high degree of automation, strong maneuverability, convenient operation and good stability.
Robust structure and compact space layout, which can guarantee flexibility and production capacity at the same time
