Concrete Plant Stationary

Mobile Phone

Capacity: 25m³/h,35m³/h.50m³/h,60m³/h,75m³/h,90m³/h,120m³/h,180m³/h,240 m³/h
PLC auto-control system for easy operation.
Belt convey or skip type convey, for your need.
Italy SICOMA Concrete Mixer (Both Twin-shaft and Planetary Mixer)
Full dust control, ensure environmental protection.
Usually applied in large size construction projects. Stationary concrete plant can be fixed on the site or located near to the construction sites.

Batching Plant Manufacturer-100%Factory

  • Product Description
  • Technical Parameter
  • Features
  • Related Cases
  • Related Products

Product Description

Concrete batching plant consists of concrete mixer, aggregate mixer, aggregate supply system, weighing system, control system, screw conveyor, cement silo, etc.

Various types: mobile concrete batching plant, stationary concrete batching plant, small concrete concrete batching plant, ready-mixed concrete batching plant
Yalong Equipment provides concrete plants ranging from 75m3/h to 120m3/h to meet the different needs of customers. Our stationary concrete batching plants include hopper concrete batching plants and belt conveyor concrete batching plants. We have a very professional technical and sales team, which can provide customers with the best specific solutions according to their needs.







Classifications Of  Yalong Machine Concrete Batching Plant For Sale

  • It can be classified into various types according to aggregate materials feeding ways, the types of concrete mixers, the concrete productivities and the specific applications etc..
  • You can find mobile type, belt conveyor type, skip hopper type, stationary type, small type, truck mounted type, wet mix type,  ready mix concrete plant, and other types

Technical Parameter

MODEL HZS75 HZS90 HZS120 HZS180
OUTPUT 75(m³/h) 90(m³/h) 120(m³/h) 180(m³/h)
INSTALLATION POWER 100kW 127kW 188kW 256KW
NUMBER OF AGGREGATE FEEDER 4pcs 4pcs 4pcs 6pcs
VOLUME OF AGGREGATE FEEDER 8m³ 12m³ 12m³ 16m³
MAX.AGGREGATE SIZE 60-80mm
MIXING HOST MODEL JS1500 MAO2250/1500 MAO3000/2000 MAO3000/2000
POWDER TANK CAPACITY 80t 100t 100t 120t
NUMBER OF POWDER TANK 2pcs 2pcs 3pcs 3pcs
HEIGHT FOR UNLOADING 3.8m 3.8m 4.0m 4.0m
AGGREGATE MEASUREMENT ACCURACY ±2%
CEMENT MEASUREMENT ACCURACY

±1%

WATER MEASUREMENT ACCURACY ±1%
ADMIXTURE MEASUREMENT ACCURACY ±1%





Features

1.Short mixing time and high production efficiency. The cycle time is 72 seconds for the hopper concrete batching plant and 60 seconds for the belt conveyor batching plant. Production efficiency is higher.
2.Weighing is accurate. The weighing system adopts precise weighing. The error is ±1%, and high-quality concrete can be obtained.
3.Eco design concept. The concrete batching plant adopts the concept of green design and meets the requirements of green production.
4.Professional design team. We have a very professional technical team, which can quickly develop the most perfect solutions according to different needs.concrete
